Heavy Duty Doypack Stand Up Pouch Packaging Machine
| MOQ: | 1 |
| Price: | Negotiations |
| Standard Packaging: | International standard packaging for shipping |
| Delivery Period: | 30 days |
| Payment Method: | L/C,T/T,Western Union |
| Supply Capacity: | 300 sets per year |
Heavy Duty Doypack packaging machine
,Stand up pouch packing machine
,Premade pouch packaging machine with warranty
This heavy duty doypack stand up pouch packaging machine is built for B2B processing factories that need 24-hour non-stop continuous packaging output in peak production season. Its thickened steel frame and upgraded durable transmission structure greatly reduce mechanical wear during long time continuous operation, effectively extending the machine service life.
Different from light-duty packaging machines that can only run 8 hours a day, this heavy-duty model can keep stable 30-120 bags per minute output for 24 hours continuously, no frequent shutdown for heat dissipation is needed. It is fully compatible with regular stand up pouch, spout pouch and special shape custom pouches, covering most common food packaging scenarios.
The machine is equipped with reinforced sealing cylinder and high stability servo motor, which maintains consistent sealing pressure even after long time running, ensuring every pouch gets flat and tight sealing. The PLC touch screen interface allows operators to adjust parameters easily, no complicated professional training required.
We provide on-site installation guidance and overseas after-sales engineer support. This heavy duty stand up pouch packaging machine has become the preferred choice for B2B clients who run large-scale processing business and cannot afford unexpected long downtime.
| Model | WG-210 | WG-250 | WG-300 |
|---|---|---|---|
| Bag Size | Length: 120-380mm Width: 90-210mm |
Length: ≤400mm Width: 130-260mm |
Length: ≤400mm Width: 160-300mm |
| Packing Speed | ≤70 bags/min | ≤70 bags/min | ≤65 bags/min |
| Work Stations | 8 | 8 | 8 |
| Packaging Formats | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches |
| Power Supply | 380V | 380V | 380V |
| Total Power | 8Kw | 8Kw | 8Kw |
| Air Consumption | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min |
| Film Material | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films |
| Machine Weight | 500kg | 580kg | 850kg |
| Machine Dimensions | 1700*1140*1470 mm | 1850*1250*1520 mm | 2100*1500*1520 mm |
- Designed in accordance with GMP standards and CE certified
- Full servo control system for reliable, fast, and precise operation
- Empty bag tracking and monitoring device prevents sealing without bag opening, saving packaging materials
- Eight-station structure with centralized control via programmable PLC and six flat touch screens for simple operation
